SHTC3 High Precision Temperature Humidity Sensor
SHTC3 output calibrated digital signal. It utilizes an exclusive digital-signal-collecting technique and humidity sensing technology, assuring its reliability and stability.
$6.99
7 in stock
This item: SHTC3 High Precision Temperature Humidity Sensor
7 in stock
$6.99
$6.99
Delivery & Return
We want you to be happy with your purchase and we apologize if it is not. For whatever reason that you are not satisfied, we would be most happy to provide exchanges and returns for all items purchased from us if the following conditions are met.
Rules
All exchanges and returns would need to be raised within 10 days of the invoice date for Singaporeorders, and 20 days for overseas orders. For local deliveries, there is an option to exchange at any of our boutiques within Singaporeor through our online portal at www.company.com. All requests for returns however, would need to be strictly made online at www.company.com for both local and overseas deliveries.
Interpretation and Definitions
All exchanges and returns would need to be raised within 10 days of the invoice date for Singaporeorders, and 20 days for overseas orders. For local deliveries, there is an option to exchange at any of our boutiques within Singaporeor through our online portal at www.company.com. All requests for returns however, would need to be strictly made online at www.company.com for both local and overseas deliveries.
Description
Additional information
Q & A
SHTC3 High Precision Temperature Humidity Sensor enables temperature measurement in the range from -40 ° C to 125 ° C with an accuracy of ± 0.2 ° C and humidity measurement in the range from 0% to 100% RH with an accuracy of ± 2% RH.
SHTC3 uses the I2C interface for communication purposes.
Specifications:
- Humidity measurement range: 0~100%RH
- Humidity measurement accuracy: ±2%RH
- Temperature measurement range: -40~125°C
- Temperature measurement accuracy: ±0.2 °C
- Working voltage: 3.3~5VDC
- I2C interface output
Pin description:
- VDD power supply 3.3 ~ 5.5V DCG
- ND ground, negative power supply
- DA serial data, two-way portS
- CL serial clock, input port
Package includes: 1 x SHTC3 High Precision Temperature Humidity Sensor with cablesÂ
Check out our On Sale and Clearance ItemsÂ
Development Resources: Demo Codes, Schematics, Datasheets, Etc
   Hackaday serves up Fresh Hacks Every Day from around the Internet.
Instructables is a community for people who like to make things. Explore, share, and do your next project with us!
   Where the world builds software
  Raspberry Pi Foundation What would you like to make today?
  Arduino‘s mission is to enable anyone to enhance their lives through accessible electronics and digital technologies.
   Wikipedia is a free online encyclopedia created and edited by volunteers worldwide and hosted by the Wikimedia Foundation.
Notes:
1. There may be small size Deviations due to manual measurement, different Measuring methods and tools.
2. The picture may not reflect the actual colour of the item because of different Photographing lights, angles and display monitors.
.
| Weight | 0.010 kg |
|---|---|
| Dimensions | 6 × 3 × 1 cm |
