NodeMCU ESP8266 Expansion Base Board
NodeMCU ESP8266 Expansion Base Board is an expansion board designed to work with the NodeMCU V3 ESP8266 ESP-12E. Powered by 6V to 24V DC input
5 in stock
5 in stock
Delivery & Return
We want you to be happy with your purchase and we apologize if it is not. For whatever reason that you are not satisfied, we would be most happy to provide exchanges and returns for all items purchased from us if the following conditions are met.
Rules
All exchanges and returns would need to be raised within 10 days of the invoice date for Singaporeorders, and 20 days for overseas orders. For local deliveries, there is an option to exchange at any of our boutiques within Singaporeor through our online portal at www.company.com. All requests for returns however, would need to be strictly made online at www.company.com for both local and overseas deliveries.
Interpretation and Definitions
All exchanges and returns would need to be raised within 10 days of the invoice date for Singaporeorders, and 20 days for overseas orders. For local deliveries, there is an option to exchange at any of our boutiques within Singaporeor through our online portal at www.company.com. All requests for returns however, would need to be strictly made online at www.company.com for both local and overseas deliveries.
This NodeMCU ESP8266 Expansion Base Board is an expansion board designed to work with the NodeMCU V3 ESP8266 ESP-12E. Powered by 6V to 24V DC input, it provides the support power to operate the NodeMCU V3 and provide an easy connection to all of its input and output pins to help you connect your NodeMCU board to other devices.
Features:
- Barrel Input Connector for DC Voltage Input for AC/DC Adapters (6-24VDC)
- All NodeMCU Lolin V3 pinouts are brought on headers
- Multiple Header pins for ease of connectivity with other external devices
- On-Board Switch-mode 5V regulator
- Power Supply Headers for :
- VIN
- +5V
- 3.3V
- USB VCC / VUSB
- Antenna Mark for Correct orientation of the NodeMCU module insertion
- Onboard LED indicator
Technical Specifications:
- Input Voltage: 6V – 24V DC
- PCB Thickness: 1.6mm
- NodeMCU Pin Distance between sides: ~28.0mm
- Pin Pitch: 2.54mm (0.1in)
- Board Dimensions: 60.0mm x 60.0mm x 15.0mm (L x W x H)
- Weight: 22.5 g
Note: NodeMCU ESP8266 Expansion Base Board ESP8266 (not compatible with V2)
Development Resources: demo codes, schematics, datasheets, etc
YouTube: Take a look at NodeMCU Baseplate
Notes:
1. There may be slight size deviations due to manual measurement, different measuring methods and tools.
2. The picture may not reflect the actual colour of the item because of different photographing light, angle and display monitor.
| Weight | 0.030 kg |
|---|---|
| Dimensions | 8 × 8 × 2 cm |
